Tecnica 211/S Inverter Welder Machine
Instruction Manual
EXPLANATION OF DANGER, MANDATORY AND PROHIBITION SIGNS.
| DANGER OF ELECTRIC SHOCK | |
 |
ANGER OF WELDING FUMES |
 |
DANGER OF EXPLOSION |
 |
WEARING PROTECTIVE CLOTHING IS COMPULSORY |
 |
WEARING PROTECTIVE GLOVES IS COMPULSORY |
 |
DANGER OF ULTRAVIOLET RADIATION FROM WELDING |
 |
DANGER OF FIRE |
 |
DANGER OF BURNS |
 |
DANGER OF NON-IONISING RADIATION |
| GENERAL HAZARD | |
 |
DO NOT USE THE HANDLE TO HANG THE WELDING MACHINE. |
 |
EYE PROTECTIONS MUST BE WORN |
 |
NO ENTRY FOR UNAUTHORISED PERSONNEL |
 |
WEARING A PROTECTIVE MASK IS COMPULSORY |
 |
USERS OF VITAL ELECTRICAL AND ELECTRONIC APPARATUS MUST NEVER USE THE MACHINE – |
 |
PEOPLE WITH METAL PROSTHESES ARE NOT ALLOWED TO USE THE MACHINE |
 |
DO NOT WEAR OR CARRY METAL OBJECTS, WATCHES OR MAGNETISED CARDS |
 |
NOT TO BE USED BY UNAUTHORISED PERSONNEL |
| Symbol indicating separation of electrical and electronic appliances for refuse collection. The user is not allowed to dispose of these appliances as solid, mixed urban refuse, and must do it through authorised refuse collection centres. |
FIG. H
 |
 |
 |
 |
| ADVANCEMENT TOO SLOW | ARC TOO SHORT | CURRENT TOO LOW | CURRENT CORRECT |
 |
 |
 |
|
| ADVANCEMENT TOO FAST | ARC TOO LONG | CURRENT TOO HIGH |
TAB.1
WELDING MACHINE TECHNICAL DATA – DATI TECNICI SALDATRICE –
 |
 |
 |
 |
 |
|||
| I2max | 115V | 230V | 115V | 230V | mm 2 | kg | dB(A) |
| 80A | T20A | T10A | 32A | 16A | 10 | 2.9 | <85 |
| 125A | – | T16A | – | 16A | 10 | 3.4 | <85 |
| 150A | – | T16A | – | 16A | 10 | 3.4 | <85 |
| 160A | – | T16A | – | 16A | 10 | 3.5 | <85 |
|
|
|
|
|
|||
| I2max | 115V | 230V | 115V | 230V | mm 2 |
kg | dB(A) |
| 130A | – | T16A | – | 16A | 10 | 3.7 | <85 |
| 150A | – | T16A | – | 16A | 10 | 3.7 | <85 |
| 180A | – | T16A | – | 16A | 10 | 3.7 | <85 |
|
|
|
|
|
|||
| I2max | 115V | 230V | 115V | 230V | mm 2 |
kg | dB(A) |
| 120A | T25A | – | 32A | – | 10 | 4.5 | <85 |
| 130A | – | T16A | – | 16A | 10 | 4.3/4.7 | <85 |
| 150A | – | T16A | – | 16A | 16 | 4.3 | <85 |
| 180A | – | T16A | – | 16A | 16 | 4.5 | <85 |
TAB.2
ELECTRODE HOLDER TECHNICAL DATA ACCORDING TO EN 60974-11 –
 |
||||
| I2 max (A) | I max (A) | X (%) | ø mm |  ø mm2 |
| 80+130 | 200 150 |
35 60 |
2+4 | 10 |
| 150+180 | 16 | |||
GUARANTEE
The manufacturer guarantees proper operation of the machines and undertakes to replace free of charge any parts should they be damaged due to poor quality of materials or manufacturing defects within 12 months of the date of commissioning of the machine, when proven by certification. Returned machines, also under guarantee, should be dispatched CARRIAGE PAID and will be returned CARRIAGE FORWARD. This with the exception of, as decreed, machines considered as consumer goods according to European directive 1999/44/EC, only when sold in member states of the EU. The guarantee certificate is only valid when accompanied by an official receipt or delivery note. Problems arising from improper use, tampering or negligence are excluded from the guarantee. Furthermore, the manufacturer declines any liability for all direct or indirect damages.
CERTIFICATE OF GUARANTEE
MOD
Date of buying –
Sales company (Name and Signature)
The product is in compliance with:
DIRECTIVES
LVD 2014/35/EU + Amdt.
