516 Series Rack and Panel Connector Owner’s Manual Rack And Panel Connectors Features: 0.150” (3.81mm) contact spacing x 0.130” (3.30mm) or 0.150” (3.81mm) row spacing with staggered grid Plug and receptacle in 20, 38, 56, 90 and 120 contact sizes Edacon hermaphroditic contact mating design … Read more
EDAC 345-030-520-201 Radiomag RKS Components Product Information Product Name: 345/395 Series Card Edge Connector Part Number: 345-030-520-201 Contact Dimensions: 520-P.C. Tail .030x.018(0.76×0.46) – Tail LG=.175(4.45) .100 (2.54) Contact Spacing x .200 (5.08) RowSpacing Contact Description: 559-90 Degree Bend (Code 541 Contacts) Insulator Material: Thermoplastic PBT … Read more
EDAC 391 Series Card Edge Connector Product Information The 341/391 Series Card Edge Connector is a low profile connector designed for use with printed circuit boards. It features a .100 (2.54) contact spacing and .140 (3.56) row spacing. The connector accepts .062 (1.57) nominal thickness … Read more
