SOLUM WC37FAPBDE0-SM Corrugated Box Instruction Manual
Contents
Set Contents
Check the components below in the package box.
Product Configuration Diagram
Features and Descriptions
Rear Parts of Product
Rear Parts of Product
| Port Function | Description |
 LAN |
This is connect the Internet LAN cable.. |
 USB 2.0 Type A |
This is the port where a wired terminal device (USB) mouse and USB memory are connected.. |
| USB 3.0 Type A | This is the port where a wired terminal device (USB) mouse and USB memory are connected. |
| USB Micro Type B | Use for only development |
| DC Power Input | DC 19V / 3.17A Power Supply |
| Power On/Off Switch | Power On / OFF Switch |
Installation Method
Connect peripheral devices.
- Connect the mouse via USB at the back cover of the product.
- Connect the mouse via USB at the back cover of the product.
- After turning on the power, go to Settings -> Network and Internet -> Ethernet and check whether the Network is connected properly
| Disconnect | Connect |
| IP address 00:00 |
IP address 192.168.0.7 |
| Netmask | netmask255.255.255.0 |
| gateway0000 | gateway192.168.01 |
| dns1 | dns1 168.126.63.1 |
| dns2 0:o:o:o |
dns2 168.126.63.2 |
| Ethernet Ip mode/; dhep |
Ethernet Ip mode dhep |
Product Specifications
H/W Specification
| Division | Description |
| Model Name | WC37FAPBDE0/SMWC37FAPBDE0/SM |
| DC Input | Input : DC 19V / 3.17A 59W |
| Resolution | 1920(H) x 540(V) |
| Working Temperature | 0 – 40 ̊C |
| Working Humidity | Max 80% |
| Product Size (mm) | 914.9 x 280.9 x 35 mm |
| Operating System | Android 12 |
| CPU | RK3566_ARM Cortex-A55 / 1.5GHz / Quad Core |
| RAM/ROM | 2 G bytes(LPDDR4x) / 8 G bytes(eMMC) |
Input / Output IO Specification
| Division | Description |
| Lan Port | RJ45, 10/100/1000 Mbps |
| USB Port (Blue) | USB 3.0 Type A Port (Max 1A) |
| USB Port | USB 2.0 Type Micro Port (Max 500mA) |
| DC Power Switch | ON / OFF |
Caution
FCC Information to User
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
Caution
THE GRANTEE IS NOT RESPONSIBLE FOR ANY CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE.
SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
IMPORTANT NOTE : FCC RF Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. This transmitter must not be co located or operating in conjunction with any other antenna or transmitter
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
- This device may not cause harmful interference, and
- this device must accept any interference received, including interference that may cause undesired operation of the device.
CE Traceability
Product Maker : SOLUM
Address : DONGGUAN SOLUM ELECTRONICS CO., LTD Building 4/6，NO.35,Tongzhen Road, Tongsha Science andTechnology Industrial Park, Dongcheng District, Dongguan City, Guangdong Province, 523127, China
Model Name : WC37FAPBDE0/SM WC37FAPBDU0/SM
