Vital 5 Swing Door plus Side Panel
Instruction Manual
Contents
IMPORTANT ROCOMMENDATIONS!
- Keep children away from packaging materials. The bags and transparent foil are not toys. Please ensure that these are not placed over children’s heads or parts are swallowed. danger of suffocation!
- The product is delivered with a series of screws, discs, etc. for safe assembly. These parts may be life-threatening if swallowed. For this reason, keep children at a safe distance when assembling the product.
- The assembly materials are suitable for conventional, strong walls. Please confirm that the assembly materials provided are suitable for your wall prior to assembly.
- Ensure that no piping or cables are located behind the drill hole.
- Read the assembly instructions very carefully before assembly and check the product to see if it has been damaged during transport or is defective, as we cannot assume any liability for damage to products which have already been assembled.
- We shall not be liable for damage arising as a result of improper transport or storage. read the storage instructions on the packaging!
- Before installing the product, check to make sure the type, dimensions and colour all conform to each other.
- There shall be no warranty claim on parts subject to wear and tear after the statutory warranty period has expired.
- Use only the cleaning agents recommended by retailers to clean the parts (no abrasives or solvents).
- The shower may only be used for the stipulated purpose, otherwise all product liability will lapse!
- After the sealing procedure please wait 24 hours before the first use of the shower.
- Recommendation: The assembly of the shower should be executed by two persons.
- We retain the right to change the design.
Cleaning instructions glass coating
The inside of your shower partition has been sealed with a high quality glass coating. This coating makes it easier to clean and care for thanks to its water- and dirt-repellent function. However, it is still necessary to clean the panes of glass, because otherwise a layer of mould could develop and reduce the effectiveness of the glass coating. This will be evident as it becomes difficult for water to roll down the surface, and stains will develop on the glass.
We recommend a standard domestic glass cleaner and cotton fibre cleaning cloths for this task. Vinegar- and citrus-based cleaners and microbfibre cloths are not suitable, as they may attack the surface.
To maintain the long-term effect of the glass coating, we recommend renewing it from time to time with our cleaning and restoring set.
Explosion Designes
Spare parts order
Serie Vital 5
Seitenwand
ESG 6 MM
| No. | Designation | Article No. | Pieces |
| 1. 1 2 2. oder. 2.1. 3 3. 4 4. |
 |
u-Profil Schwingtür links Schwingtür rechts Ausgleichprofil Wandanschlagsprofil |
1x 1x 1x 1x |
| 5 6. |
 |
Wand rechts / oder Wand links u-Profil |
1x 1x |
| 7 |  Montagehilfe 1,5 mm |
14 – 0000017 | 2x |
| 8 |  Dübel ø 6 mm |
4 – 0001181 | 8x |
| 9 |  4×40 A2 dIN7996 |
4 – 0000062 | 8x |
| 10 |  Rosette |
3 – 0000851 | 9x |
| 11 |  3,5×9,5 A2 dIN7981 |
4 – 0000013 | 13x |
| 12 |  Abdeckkappe |
3 – 0000850 | 9x |
| 13 |  Montagehilfe Holz 20x15x45 mm |
14 – 0000514 | 1x |
| 14 |  Wasserabweiser [Verschleißteil ***] |
62054 | 1x |
| 15 |  Schwallleiste |
—————— | 1x |
| 16 |  Griff |
6 – 0000059 | 1x |
| 17 | Stabilisator Glas/Wand rund, chrom, Länge 1.200 mm, kürzbar  Wandhalter 1x Glashalter 1x rohr 1x  dübel ø 6 mm 4×40 mm |
89461 | 1x |
| 18 |  Magnetprofil [***] |
62056 | 1x |
| 19 |  HSS-Metallbohrer ø 2,8 mm |
514 – 0000001 | 1x |
