S-TRACK Column EAGLE Z38 Speaker Owner’s Manual
Contents
Product Information
The Column EAGLE Z38 is a sound column speaker that utilizes 4/8/16 2.75-inch full-range units. The box is made of domestic laminate and features a surface baking paint process. It offers various installation methods and comes with optional installation accessories, making it suitable for installation in different places. The speaker is equipped with a built-in 70V/100V switchable transformer and has a DC impedance of 8/6/8, allowing for convenient application and achieving different audio-visual effects.
The system type is passive lacquered wooden speakers, and it has a frequency response of 220Hz-20kHz with a -10dB tolerance. The system composition consists of 8×2.75 full-range units. The box has 8 hanging points and is constructed with a black plastic powder coating and a 1.0mm steel orifice plate. It has dimensions of 104x130x610mm and weighs 5.2kg. The surface treatment of the box is laminate black polyimide spray. The connector used is a terminal with dimensions of 185x160x675mm. The net weight of the product is 5.8kg.
Product Usage Instructions
- Choose a suitable location for installation based on the desired audio coverage.
- Ensure that the installation area is free from obstructions that may affect the sound quality.
- Use the provided optional installation accessories, if necessary, to securely mount the Column EAGLE Z38 in the desired location.
- Connect the speaker’s terminal to an appropriate audio source using compatible cables.
- If required, set the built-in transformer to the desiredvoltage level (70V or 100V) based on your audio setup.
- Adjust the audio output level from the connected source device to achieve the desired volume.
- Test the audio output and make any necessary adjustments to optimize the sound quality.
- For any further assistance or inquiries, contact S-Track customer service at 400-900-2726 or via email at [email protected].
| System Type | Passive Lacquered Wooden Speakers | Frequency Response | 220Hz-20kHz, -10dB |
| System Composition | 8×2.75″ full-range unit | Box | Square Box, Laminate |
| Installation | 8 Hanging Points | Surface Treatment | Black Polyimide Spray |
| Iron Mesh | Black plastic powder coating,1.0mm steel orifice plate | Connector | Terminal |
| Speaker Size(W×D×H) | 104x130x610mm | Package Size(W×D×H) | 185x160x675mm |
| Net Weight | 5.2kg | Gross Weight | 5.8kg |
For more information about the product, visit the official
website: at www.s-track.cn.
: 400-900-2726
: [email protected]
: www.s-track.cn
: 9/F, Block B, Building 1, Shangzhi Technology Park, Fenghuang Street, Guangming District, Shenzhen, China
