INSTRUCTION MANUAL

105511 Zuzanna HL 5 Black Gold Smoke

QAZQA 105511 Zuzanna HL 5 Black Gold Smoke - Symbol 2

Zuzanna HL 5 Black Gold Smoke
105511

QAZQA 105511 Zuzanna HL 5 Black Gold Smoke

SAFETY INSTRUCTION

Please study the instruction manual and below information carefully before installing or using this product.
Please keep this user manual for further reference

  1. The luminaires may only be installed by authorized and qualified technicians according the valid regulations for electrical installation.
  2. Maintenance of the luminaires is limited to their surfaces. During maintenance no moisture can come into contact with any areas of the terminal connections or voltage control parts.
  3. The electrical supply must be switched off at the outset, preferably by means of a switch in the distribution box, before any installation, maintenance or repair work is undertaken.
  4. Exterior lighting must not be installed during rain.
  5. Take account of the minimal separation distance from other objects and the room required around the fitting.
  6. If in any doubt, consult a professional, taking local installation requirements into account. Some countries stipulate that lighting may be installed only by registered installers.
  7. Clamping screws in electrical connections must be adequately tightened. This is particularly the case with 12V low voltage conductors.
  8. Clean with a clean, dry cloth or brush, use no solvents or abrasives. Avoid dampness on all electrical components
  9. Take account of all available technical information.
  10. Meaning of symbols:
    QAZQA 105511 Zuzanna HL 5 Black Gold Smoke - Symbol 1 For indoor use only, where direct contact with water is impossible
    QAZQA 105511 Zuzanna HL 5 Black Gold Smoke - Symbol 3 This icon indicates the level of water-proof and dust-proof
    QAZQA 105511 Zuzanna HL 5 Black Gold Smoke - Symbol 4 Protection Class I: the fitting must be earthed
    QAZQA 105511 Zuzanna HL 5 Black Gold Smoke - Symbol 5 Protection Class II: the fitting is doubled insulated and does not require earthing
    QAZQA 105511 Zuzanna HL 5 Black Gold Smoke - Symbol 6 Protection Class III: the fitting is low voltage
    QAZQA 105511 Zuzanna HL 5 Black Gold Smoke - Symbol 7 Minimum distance from lighted objects (meters)
    QAZQA 105511 Zuzanna HL 5 Black Gold Smoke - Symbol 8 The type of lamp and maximum size and wattage indicated in each lighting unit must not be exceed; different items require different kind of light sources with different bulb icons
    QAZQA 105511 Zuzanna HL 5 Black Gold Smoke - Symbol 9 The armature is designed to work only with the indicated voltage. Different items require different working voltage.
    QAZQA 105511 Zuzanna HL 5 Black Gold Smoke - Symbol 10 The luminaire can be used in combination with a dimmer
    QAZQA 105511 Zuzanna HL 5 Black Gold Smoke - Symbol 11 The luminaire can be dimmed by wall switch
    QAZQA 105511 Zuzanna HL 5 Black Gold Smoke - Symbol 12 The reference light angle and light space of the luminaire
    QAZQA 105511 Zuzanna HL 5 Black Gold Smoke - Symbol 13 This luminaire cannot be disposed together with normal domestic waste in standard rubbish can, but you have to bring it to a staging area for electrical waste
  11. Take note of the symbols when connecting wires:
QAZQA 105511 Zuzanna HL 5 Black Gold Smoke - Symbol 14 L Live conductor
Earth conductor
N Neutral conductor
