PHILIPS WT490C LED Gen5 Pacific Luminaires Installation Guide

PHILIPS WT490C LED Gen5 Pacific Luminaires

Product Information

Specifications

• Product Name: Pacific LED gen5
• Luminare Type: Indoor
• LEDs: 10
• Voltage: 220V – 240V
• Frequency: 50Hz – 60Hz
• Minimum Distance from Surface: 60 cm
• Lifetime: 100,000 hours (L80)
• IP Rating: IP66
• Impact Protection: IK08
• Light Source Efficiency Class: C

Product Usage Instructions

Installation

1. Prevent water from entering the luminaire during installation and use. Refer to the manual for installation details.
2. Do not open the luminaire when it is powered up to avoid the risk of electrostatic discharge.
3. The housing is made of non-metallic material. Prevent dust accumulation on the surface of the housing.
4. Clean the luminaire only with a damp cloth containing antistatic agents.

Mounting Options

Ceiling Mounting (Standard Applications)

• For ceiling mounting, follow the standard installation instructions provided in the manual.

Wall Mounting Applications

• If you want to mount the luminaire on a wall in vertical and/or horizontal positions, you will need to use a special set of screws and nuts (WT470Z SCREW-VP SET (10PCS), EOC: 871869638509800, 12NC: 910925864392) supplied as accessories.

Electrical Connections

• The product comes with a Wieland connector (female) included in the box. Use this connector for electrical connections.

FAQ

Q: What is the maximum ambient temperature for the Pacific LED gen5?

• The maximum ambient temperature for the Pacific LED gen5 is T45.

Q: What is the lifetime of the Pacific LED gen5?

• The Pacific LED gen5 has a lifetime of 100,000 hours (L80).

Q: Can I clean the luminaire with any cleaning agent?

• No, you should only clean the luminaire with a damp cloth containing antistatic agents.

WHAT’S IN THE BOX

Features

• Prevent water from entering or in the luminaire during the installation and use phase.
• Refer to the manual for installation details.
• Do not open when power up, risk of electrostatic discharge!
• The housing is made of non-metallic material.
• Prevent dust accumulation on the surface of the housing.
• Clean a luminaire only with a damp cloth containing an antistatic agent.

Luminaire type		System flux [lm] NB-HRO, WB, VWB/ O	Driver type	P(W)	Max ambient temperature
WT495C L1200	42S	4200/ 4000	75W PSU	25,5	T55
			35W PSD	26,0
	64S	6400/ 6200	100W PSU	40,5	T60
			100W PSD	40,5
	80S	8000/ 7600	100W PSU	51,0
			100W PSD	51,0
WT495C L1800	80S	8000/ 7600	100W PSU	49,0
			100W PSD	48,5
	100S	10000/ 9600	100W PSU	62,0
			100W PSD	62,0

• The light source of energy efficiency class: C
• Lumen output provided for 4000K, 6500K options, in 3000K lumen output will be on average approx.7% less.

Dimension

Luminaire type	A [mm]	B [mm]	C [mm]	max
WT490C/ WT495C L700 (TCW5)	360 – 260	660	686	1,6
WT490C/ WT495C L1200 (TCW5)	920 – 720	1221	1248	2,4
WT490C/ WT495C L1600 (TCW5)	1300 – 1100	1601	1628	3,0
WT490C/ WT495C L1800 (TCW5)	1480 – 1080	1783	1810	3,2

Luminaire type	A [mm]	B [mm]	D [mm]	max
WT490C/ WT495C L1200 TW	920 – 720	1224	1278	2,8
WT490C/ WT495C L1600 TW	1300 – 1100	1601	1654	3,4
WT490C/ WT495C L1800 TW	1480 – 1080	1785	1838	3,6

INSTALLATION INSTRUCTION

Inrush current

PSED, SEIA version (Emergency Lighting)

For emergency lighting requires a DC power connection (186…250V DC)

Luminaire type		Rounded DC EL Power [W]	Rounded flux 830 [lm]	Rounded flux 840 [lm]
WT490C L700	23S	3,4	320	340
WT490C L1200	35S	4,4	490	520
	42S	5,0	600	640
	64S	8,0	900	690
	80S	9,7	1100	1200
	100S	11,6	1400	1500
WT490C L1600	35S	4,4	490	520
	42S	5,0	600	640
	64S	8,0	900	690
	80S	9,7	1100	1200
WT490C L1800	80S	13,6	1100	1200
	100S	13,6	1400	1500
	120S	13,6	1700	1800
	150S	16,6	2100	2300

Luminaire type		Rounded DC EL Power [W]	Rounded flux 830 [lm]	Rounded flux 840 [lm]
WT495C L1200	42S	5,6	600	640
	64S	7,7	900	690
	80S	8,8	1100	1200
WT490C L1800	80S	8,7	1100	1200
	100S	10,6	1400	1500

			PSU 35W	PSD 35W	SIA 35W	PSD 60W	SIA 60W	PSU 75W	PSU 90W	PSD 90W	PSU 100W	PSD 100W	SIA 90W	PSU 100W	PSD 100W
ELECTRICAL CHARACTERISTICS	DRIVER	TYPE	WT490C 23S (PSU), 35S (PSU)	WT490C/ WT495C 23S (CLO), 35S (CLO), 42S	WT490C 35S (CLO), 42S (CLO) (SIA)	WT490C 64S (CLO), 80S (CLO), 100S (CLO) (PSD)	WT490C 64S (CLO), 80S (CLO), 100S (CLO)	WT490C 42S, 64S, 80S, 100S, 120S (PSU)	WT490C 100S (PSU)	WT490C 100S (CLO), 120S (CLO) (PSD)	WT490C 150S (PSU)	WT490C 150S (CLO) (PSD)	WT490C 80S (CLO), 100S (CLO), 120S (CLO), 150S (CLO) (SIA)	WT495C 64S, 80S, 100S (PSU)	WT495C 64S, 80S, 100S (CLO)(PSD)
		Leak current [mA rms]	0,7	0,5	0,5	0,5	0,5	0,3	0,7	0,5	0,5	0,5	0,5	0,5	0,5
		Imax [A]	17,0	23,1	20,0	25,1	23,0	19,0	21,0	25,0	22,5	10,0	25,0	9,0	4,5
		Tref [μs]	244	221	216	214	194	280	316	230	30	35,9	230	65	1000
		MCB-16A	33	22	24	21	24	24	19	20	23	18	20	26	24
	No of Luminaires per MCB	Cable Section [mm2]	1.5mm2, 2.5mm2 / TI3 [EN 50525-1]
		B-6A	13	8	9	8	9	9	7	8	9	7	8	9	5
		B-10A	20	13	15	13	15	15	11	12	14	11	12	15	15
		C-10A	34	22	24	21	24	24	19	20	23	18	20	29	24
		B-13A	26	17	19	17	19	19	15	16	18	14	16	19	19
		C-13A	44	29	32	28	32	32	25	27	29	24	27	32	32
		B-16A	33	22	24	21	24	24	19	20	23	18	20	26	24
		C-16A	56	37	36	35	36	36	32	34	29	20	34	36	40
		Cable Section [mm2]	2.5mm2 / TI3 [EN 50525-1]
		B-20A	41	27	30	26	30	30	23	25	28	22	25	30	30
		C-20A	45	45	36	43	36	36	35	35	29	29	41	36	49

Maintenance instructions

To ensure the lighting quality of this unique LED lighting concept a few instructions are regarding the maintenance of this LED luminaire:

1. Do not touch electronic components!
   • Electronic components are under high voltage.
   • Electronic components are ESD-sensitive.
2. During installation or when maintaining the luminaire please use static-free gloves to avoid marks on the luminaire.
3. To remove dirt and spots use the following:
   Dust: only use microfiber cloths Fingerprints, etc.: use a cleaner for synthetic materials with antistatic properties.
4. Do not stare into the LED light beam.
5. To avoid scratches and dirt on optical parts remove protective foil after installation.
6. The luminaire shall be installed by a qualified electrician and wired under the latest IEE electrical regulations or the national requirements.
7. Do not touch either the LEDs or the contacts into the connector Install carefully the optical plates to protect the boards.
8. Driver insulation: Basic according to IEC 61847-1.

QR CODE

• To get an overview of all spare parts for a luminaire, please refer to detailed instructions in the service manual available via the Signify Service tag apps (Android and iOS).
• Disconnect before servicing
• Luminaire has basic insulation between Low Voltage supply and control conductors.
• The light source and/or control gear and/or the external flexible cable contained in this luminaire shall only be replaced by the manufacturer his service agent or a similarly qualified person.
• Storage, installation, use, operation, and maintenance of the products need to be performed exactly according to the instructions in this manual and/or other instructions as may be provided by us to guarantee the safe use of the product over its entire lifetime.
• Failure to adhere to these instructions will invalidate your entitlement to warranty. Bolts with the indication of torque strength on the drawing need to be tightened using a calibrated torque wrench.
• Pre-assembled bolts need to be retightened again to the required torque specification to ensure maximum strength over a lifetime.
• This product contains a light source of energy efficiency class: see table or label.
• Printed in Poland
• Data subject to change without notice
• Keep for future reference: www.philips.com/lighting.
