Ledinaire
Surface-mounted
SM060C
SM060C Ledinaire Surface Mounted Light
| System lumen | CCT | Driver | Light source of energy efficiency class | P(W) |  |
|
| SM060C LED34S/840 PSU W20L120 NOC | 3400lm | 4000K | PSU | E | 34 | 2.62 |
| SM060C LED40S/840 PSU W20L120 NOC | 3400lm | 40 | 2.62 | |||
| SM060C LED34S/840 PSU W20L120 OC | 4000lm | 34 | 2.78 |
Inrush current
| LED34S | LED40S | |
| Electrical characteristics | ||
| Imax.(A) | 10.8 | 9,68 |
| Tref (µs) | 36 | 75 |
| MCB | Luminaires Max. | |
| B-16A | 15 | 15 |
| B-10A | 24 | 24 |
| C-10A | 25 | 25 |
| C-16A | 41 | 41 |
- The luminaire shall be installed by a qualified electrician and wired in accordance with the latest IEE electrical regulations or the national requirements.
- The light source and driver contained in this luminaire shall be replaced by a professional.
ATTENTION
OBSERVE PRECAUTIONS FOR HANDLING ELECTROSTATIC SENSITIVE DEVICES
This product contains a light source of energy efficiency class: see table or label.
Disconnect before servicing
Luminaire has basic insulation between Low Voltage supply and control conductors.
The light source and/or control gear and/or the external flexible cable contained in this luminaire shall only be replaced by the manufacturer or his service agent or a similar qualified person.
