Optoma WU615T DLP Projector User Guide
- Ultra Bright WUXGA projector – 6500 ANSI lumens
- Installation flexibility – 1.8x zoom
- Vertical and Horizontal lens shift
- 4 Corner geometric projection
Specifications
Display/image
- Display technology: DLP™
- Resolution: WUXGA (1920×1200)
- Brightness: 6.500 lumens
- ANSI brightness: 6.500
- Contrast ratio: 10.000:1
- Native aspect ratio: 16:10
- Aspect ratio – compatible: 4:3,16:9
- Keystone correction -: -30 ~ +30°
- horizontal
- Keystone correction – vertical: -30 ~ +30°
- Has vertical auto keystone correction: Yes
- Displayable colours (millions): 1073.4
- Horizontal scan rate: 15.38 ~ 91.15Khz
- Vertical scan rate: 24 ~ 85(120 for 3D)Hz
- Uniformity: 85%
- Screen size: 0.71m ~ 7.62m (27.9″ ~ 300″) diagonal
Lamp info
- Light source type: Lamp
- Lamp watts: 465
- Lamp life hours (up to): 2000 (Bright), 12000 (Dynamic), 3000 (Eco), 3000 (Eco+)
Optical
- Throw ratio: 1.2:1 ~ 2.16:1
- Projection distance: (m) 1.3m – 7.8m
- Zoom: 1.8
- Zoom type: Manual
- Focal length (mm): 17.63 ~ 31.36
- Lens shift: Vertical +20%, Horizontal +10%
- Native offset: 100%
Connectivity
Connections:
Inputs 1 x RJ45, 1 x mini USB service, 1 x HDMI 1.4a 3D support + MHL, 1 x HDMI 1.4a 3D support, 1 x DisplayPort, 2 x VGA (YPbPr/RGB), 1 x S-Video, 1 x Composite video, 1 x HDBaseT, 1 x Audio RCA L&R, 2 x Audio 3.5mm, 1 x Audio 3.5mm, 1 x Mic 3.5mm
Outputs 1 x VGA (YPbPr/RGB), 1 x 3D sync, 1 x USB-A power 1.5A, 1 x 12V trigger
General
- Noise level (typical): 37dB
- Noise level (max): 39dB
- PC compatibility: FHD, UXGA, SXGA, WXGA, HD, XGA, SVGA, VGA, Mac
- 2D compatibility: NTSC M/J, 3.58MHz, 4.43MHz PAL B/D/G/H/I/M/N, 4,43MHz SECAM B/D/G/K/K1/L, 4.25/4.4MHz 480i/p, 576i/p, 720p(50/60Hz), 1080i(50/60Hz), 1080p(50/60Hz)
- 3D compatibility: Side-by-Side:1080i50 / 60, 720p50 / 60 Frame-pack: 1080p24, 720p50 / 60 Over-Under: 1080p24, 720p50 / 60
- 3D: Full 3D
- Security: Security bar, Kensington Lock, Password protected interface
- OSD / display languages: 25 languages: Arabic, Czech, Danish, Dutch, English, Farsi, Finnish, French, German, Greek, Hungarian, Indonesian, Italian, Japanese, Norwegian, Polish, Portuguese, Romanian, Russian, Chinese (simplified), Spanish, Swedish, Chinese (traditional), Turkish, Vietnamese
- 24/7 operation: Yes
- Operating conditions: 5°C ~ 40°C, Max. Humidity 85%, Max. Altitude 3000m
- Remote control: Backlit ProAV remote
- Speaker count: 2
- Watts per speaker: 10W
- In the box: AC power cord, remote control, Battery, basic user manual
- Optional wireless models: QuickCast Bundle, QuickCast starter kit, WHD200
Networking
- LAN – control: Yes
Power
- Power supply: 100V ~ 240V ± 10%, 50-60Hz
- Power consumption (standby): 0.5W
- Power consumption (min): 490W
- Power consumption (max): 615W
Weight and dimensions
Dimensions (W x D x H) mm: 424 x 344 x 160
Gross weight: 8.55 kg
Net weight: 7.27 kg
