A-Code M12 to Pigtail Power and I/O Cable
The A-Code M12 to Pigtail Power and I/O Cable (NI part number 145233-03) provides power to the NI ISC-178x smart camera and transmits digital 1/O signals.
Figure 1. A-Code M12 to Pigtail Power and I/O Cable Pinout
Table 1. A-Code M12 to Pigtail Power and I/O Cable Wire Designations
| Pin | Signal | Color | Description |
| 1 | COUT | Brown | Common reference (negative) for isolated outputs |
| 2 | Analog Out | Blue | Analog reference output for lighting controller |
| 3 | Iso Out 2+ | White | General-purpose isolated output (positive) |
| 4 | V | Green | System power voltage (24 VDC ± 10%) |
| 5 | Iso In 0 | Pink | General-purpose isolated input |
| 6 | CIN | Yellow | Common reference (positive or negative) for isolated inputs |
| 7 | Iso In 2 | Black | General-purpose isolated input |
| 8 | Iso In 3 | Gray | (NI Linux Real-Time) Reserved for safe mode
(Windows) General-purpose isolated input |
| 9 | Iso In 1 | Red | General-purpose isolated input |
| 10 | Iso Out 0+ | Violet | General-purpose isolated output (positive) |
| 11 | C | Gray/pink | System power and analog reference common |
| 12 | Iso Out 1+ | Red/blue | General-purpose isolated output (positive) |
