MEAN WELL GST160A Series 160W AC-DC Reliable Green Industrial Adaptor Owner’s Manual
MEAN WELL GST160A Series 160W AC-DC Reliable Green Industrial Adaptor Owner's

Features

  • Global certificates
  • Universal AC input/ Full range
  • 3 pole AC inlet IEC320-C14, Class I power unit
  • Built-in active PFC function
  • No load power consumption<0.15W
  • Energy efficiency Level VI
  • Comply with EISA 2007/DoE, NRCan, AU/NZ MEPS, EU ErP and CoC Version 5
  • Protections: Short circuit/Overload / Over voltage / Over temperature
  • 30~+70°C wide range working temperature
  • Fully enclosed plastic case
  • LED indicator for power on
  • Various DC plug quick adaptor accessory available (Plug kit sold desperately, please refer to: https://www.meanwell.com/upload/pdf/DC plug.pdf)
  • 3 years warranty

Applications

  • Consumer electronic devices
  • Telecommunication devices
  • Office facilities
  • Industrial equipment

GTIN CODE

MW Search: https://www.meanwell.com/serviceGTIN.aspx

Description

GST160A is a highly reliable, 160W desktop style single-output green adaptor series. This product is a class I power unit (with FG), equipped with a standard IEC320-C14 AC inlet and adopting the input range from 85VAC to 264VAC. The entire series supplies different models with output voltages ranging between 12VDC and 48VDC that can satisfy the demands for various types of consumer electronic devices. With the efficiency up to 94% and the extremely low no-load power consumption below 0.15W,GST160A is compliant with USA EISA 2007/DoE, Canada NR Can, Australia and New Zealand MEPS, Korea K-MEPS, EU ErP and Code of Conduct (CoC) Version 5. The supreme feature allows the adaptor to save the energy when it is either under the operating mode or the standby mode. The entire series utilises the 94V-0 flame retardant plastic case. GST160A is certified for the international safety regulations.

Model Encoding

SPECIFICATION

ORDER NO. GST160A12-R7B GST160A15-R7B GST160A20-R7B GST160A24-R7B GST160A36-R7B GST160A48-R7B
OUTPUT SAFETY MODEL NO. GST160A12 GST160A15 GST160A20 GST160A24 GST160A36 GST160A48
DC VOLTAGE                Note.2 12V 15V 20V 24V 36V 48V
RATED CURRENT 11.5A 9.6A 8A 6.67A 4.44A 3.34A
CURRENT RANGE 0 ~ 11.5A 0 ~ 9.6A 0 ~ 8A 0 ~ 6.67A 0 ~ 4.44A 0 ~ 3.34A
RATED POWER (max.) 138W 144W 160W 160W 160W 160W
RIPPLE & NOISE (max.) Note.3 80mVp-p 100mVp-p 120mVp-p 150mVp-p 150mVp-p 200mVp-p
VOLTAGE TOLERANCE Note.4 ±5.0% ±5.0% ±4.0% ±3.0% ±3.0% ±3.0%
LINE REGULATION          Note.5 ±1.0% ±1.0% ±1.0% ±1.0% ±1.0% ±1.0%
LOAD REGULATION ±5.0% ±5.0% ±4.0% ±3.0% ±3.0% ±3.0%
SETUP, RISE TIME          Note.6 2000ms, 50ms / 230VAC           2500ms, 50ms / 115VAC at full load
HOLD UP TIME (Typ.) 20ms / 230VAC          20ms / 115VAC at full load
INPUT VOLTAGE RANGE           Note.7 85 ~ 264VAC  120 ~ 370VDC
FREQUENCY RANGE 47 ~ 63Hz
POWER FACTOR (Typ.) 12V/15V:PF>0.93 / 230VAC           20V,24V,48V:PF>0.94 / 230VAC            PF>0.98 / 115VAC at full load
EFFICIENCY (Typ.) 90% 91% 93% 93% 92% 94%
AC CURRENT 1.85A / 115VAC          1A / 230VAC
INRUSH CURRENT (max.) Cold start 95A / 115VAC       120A / 230VAC
LEAKAGE CURRENT(max.) 0.75mA / 240VAC
PROTECTION OVERLOAD 105 ~ 150% rated output power
Protection type : Hiccup mode, recovers automatically after fault condition is removed
OVER VOLTAGE 105 ~ 135% rated output voltage
Protection type : Hiccup mode @ 10%load
OVER TEMPERATURE Protection type : Shut down o/p voltage, re-power on to recover
ENVIRONMENT WORKING TEMP. -30 ~ +70℃ (Refer to “Derating Curve”)
WORKING HUMIDITY 20% ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY -40 ~ +85℃ , 10 ~ 95% RH non-condensing
TEMP. COEFFICIENT ±0.03% / ℃ (0~50℃ )
VIBRATION 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
SAFETY & EMC(Note. 10) SAFETY STANDARDS Note. 8 UL62368-1, CSA C22.2 No.62368-1, TUV BS EN/EN62368-1, BSMI CNS14336, CCC GB4943.1, PSE J62368-1,AS/NZS 60950.1BIS IS13252, KC K60950-1, EAC TP TC 004 approved; SIRIM MS IEC60950-1 (optional) approved
WITHSTAND VOLTAGE I/P-O/P: 3KVAC  I/P-FG: 2KVAC  O/P-FG:SHORT
ISOLATION RESISTANCE I/P-O/P:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION Parameter Standard Test Level / Note
Conducted emission BS EN/EN55032(CISPR32),FCC PART 15 / CISPR22CAN ICES-3(B)/NMB-3(B),CNS13438,GB17625.1 EAC TP TC 020,MSIP KN32 Class B
Radiated emission BS EN/EN55032(CISPR32),FCC PART 15 / CISPR22CAN ICES-3(B)/NMB-3(B),CNS13438,GB17625.1 EAC TP TC 020,MSIP KN32 Class B
Harmonic current BS EN/EN61000-3-2,GB9254 Class A
Voltage flicker BS EN/EN61000-3-3 ——-
EMC IMMUNITY BS EN/EN55035
Parameter Standard Test Level /Note
ESD BS EN/EN61000-4-2 Level 4, 15KV air; Level 4, 8KV contact
RF field susceptibility BS EN/EN61000-4-3 Level 2, 3V/m
EFT bursts BS EN/EN61000-4-4 Level 3, 2KV
Surge susceptibility BS EN/EN61000-4-5 Level 3, 1KV/Line-Line , 2KV/Line-FG
Conducted susceptibility BS EN/EN61000-4-6 Level 2, 3V
Magnetic field immunity BS EN/EN61000-4-8 Level 2, 3A/m
Voltage dips , interruption BS EN/EN61000-4-11 ＞95% dip 0.5 periods, 30% dip 25 periods,＞95% interruptions 250 periods
OTHERS MTBF 2205.4K hrs min.    Telcordia SR-332 (Bellcore) ; 236.4K hrs min.             MIL-HDBK-217F (25℃)
DIMENSION 175*72*35mm (L*W*H)
PACKING 0.66Kg; 20pcs/ 14.2Kg/ 0.95CUFT
CONNECTOR PLUG See page 4~5 ; Other type available by customer requested
CABLE See page 4~5 ; Other type available by customer requested
NOTE
  1. All parameters are specified at 230VAC input, rated load, 25℃ 70% RH ambient.
  2. DC voltage: The output voltage set at point measure by plug terminal & 50% load.
  3. Ripple & noise are measured at 20MHz by using a 12″ twisted pair terminated with a 0.1μF & 47μF capacitor.
  4. Tolerance: includes set up tolerance, line regulation, load regulation.
  5. Line regulation is measured from low line to high line at rated load.
  6. Length of set up time is measured at first cold start. Turning ON/OFF the power supply may lead to increase of the set up time.
  7. Derating may be needed under low input voltage. Please check the derating curve for more details.
  8. The demand for Malaysia safety is processed with the order no. GST160A  -SIRIM by request. Please contact MEAN WELL for details.
  9. The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).
  10. The power supply is considered as an independent unit, but the final equipment still need to re-confirm that the whole system complies with the EMC directives. For guidance on how to perform these EMC tests, please refer to “EMI testing of component power supplies.” (as available on https://www.meanwell.com//Upload/PDF/EMI_statement_en.pdf )
from File Name: GST160A-SPEC   2024-01-26

Derating Curve

Static Characteristics

Mechanical Specification

DC output plug

◎ Standard plug: R7B

R7B Pin Assignment
PIN NO OUTPUT
1 +Vo
2 -Vo
3 -Vo
4 +Vo

DC plug changeable through:

  1. Customisation of the standard part with an optional DC plug according to the table (MOQ applicable)
  2. Quick adapter accessory (sold separately without MOQ) Please refer to below table and online selection guide : https://www.meanwell.com/upload/pdf/DC_plug.pdf

Example quick adapter accessory:

Optional DC plug: (Available in customised cable or quick adaptor)

Tuning Fork Style Type No. A B C Quick Adaptor Accessory
OD ID L
(Straight) P1J 5.5 2.1 11.0 Available for 24 ~ 48V(Current rating: 7.5A max.)
P1M 5.5 2.5 11.0
Min. DIN 4 Pin with Lock (female) Type No. Pin Assignment None
PIN No. Output
KY CON KPJX-CM-4S equivalent
Optional DC plug		 R7BF 1 +Vo
2 -Vo
3 -Vo
4 +Vo
DIN 5 Pin (male) Type No. Pin Assignment None
PIN No. Output
Optional DC plug R1B 1 -Vo
2 -Vo
3 +Vo
4 -Vo
5 +Vo
NEUTRINO XLR NC4FX equivalent Type No. Pin Assignment None
PIN No. Output
Optional DC plug MIC4 1 +Vo
2 +Vo
3 -Vo
4 -Vo
MOLE 39-01-2060 (4.2mm) equivalent Type No. Pin Assignment None
PIN No. Output
FG not connected to output connector
Optional DC plug		 C6P 1 +Vo
2 +Vo
3 +Vo
4 -Vo
5 -Vo
6 -Vo
AMP 1-480702-0 (6.35mm) equivalent Type No. Pin Assignment Quick Adapter Accessory
PIN No. Output
FG not connected to output connector
Optional DC plug		 C4P 1 +Vo None
2 +Vo
3 -Vo
4 -Vo
Stripped and tinned leads Type No. Pin Assignment None
PIN No. Output
Length of Land L1 by request(MW’s standard length, L: 25 mm, L1: 5 mm)
( NOTE: The wire color is for reference only,please refer to the actual product)
Optional DC plug		 by customer 1 +Vo
2 -Vo
