Maxxima MEL-S101300W-B LED Outdoor Flood Wall Light

Maxxima MEL-S101300W-B LED Outdoor Flood Wall Light

Symbol WARNINGS Symbol
  •  Risk of electric shock – Disconnect power at the source before installation.
  • If you are unsure about the installation or the maintenance of the wall light, please consult an electrician.
  • Do not make or alter any holes in the wiring enclosure or modify any electrical componentry.

CAUTIONS
  • To ensure personal safety, proper grounding of the electrical fixture is required.
  • The fixture must be wired in accordance with the National Electric Code and applicable local codes or ordinances.

WIRING INSTRUCTIONS

  1. Ensure that power has been turned off by switching the circuit breaker or by removing the fuse from the fuse panel.
  2. If you are replacing an existing fixture, remove and disconnect the old fixture first.
  3. Expose the supply wires from the junction box.
  4. Position the supply wires with the white supply wire on one side of the junction box and the black supply wire on the other side.
  5. Connect the fixture ground wire(yellow w/ green stripe) to the junction box ground wire by using a wire connector.
  6. Connect the white wire from the fixture assembly to the white supply wire(neutral) from the post using a wire connector.
  7. Connect the black wire from the fixture assembly to the black supply wire(hot) from the post using a wire connector.
    Wiring Instructions

FIXTURE MOUNTING INSTRUCTIONS

  1. After all connections are secure, carefully tuck the wires into the electrical junction box. No loose strands or loose connections should be present.
  2.  Attach the fixture to the junction box by screwing in the mounting screws. Make sure no wires are pinched or exposed and that the foam ring is pressed tightly against the junction box.
  3.  To prevent moisture from entering the outlet box and the fixtures mounting plate causing a short, apply a bead of clear caulk to outline the outside of the fixtures mounting plate where it meets the wall. Leave a small space at the bottom to allow any condensation or moisture to escape.
  4. The installation is now complete. Restore the electricity and check the operation of your lighting fixture.
    Fixture Mounting Instructions

3 YEAR WARRANTY

Maxxima extends a 3 year limited warranty to the original purchase that the products listed are free from defects in material and/or workmanship only. Maxxima will replace any warrantied product to the original consumer/purchaser if the product fails because of defects due to workmanship and/or materials within the limited warranty period. Limited warranty is not transferable and applies to the original installation of the Maxxima product. This offer does not constitute in any way a product guarantee and Maxxima does not hereby assume any obligation whatsoever beyond sending a free replacement product.

Customer Support

Social Icon [email protected]
Social Icon 866-MAXXIMA (629-9462)
Social Icon www.maxximastyle.com
Social Icon 125 Cabot Court Hauppauge, NY 11788
