legrand 7 221 75 Wireless 4 Scenes Control
Contents
USE
Wireless control for 2 ON/OFF light functions or connected socket.
Controls micromodule products, connected sockets and connected dimmer switches.
Can be used as a two-way switch or to control a lighting group.
- Fixes directly on the wall or screws onto a flush-mounting box.
- Multi-gang versions can be combined with other wiring accessories.
- Fits on a piece of furniture (movable).
Can control up to 20 micromodules, connected sockets, connected dimmer switches
RANGE
| Description | Family | White | Ivory | Aluminum | Black | Dark Grey |
| Wireless remote scenario switch 4 buttons | SUNO | 7 221 75 | 7 222 75 | 7 223 75 | 7 224 75 | – |
| SEANO | 7 656 35 | – | 7 657 35 | 7 658 35 | 7 659 35 |
DIMENSIONS (mm)
| References | A | B | C |
| 7 221 75, 7 656 35 | 72.9 | 72.9 | 11.5 |
OPERATION
TECHNICAL CHARACTERISTICS
Mechanical characteristics
Protection against impacts: IK 02
Protection against solid bodies/liquids:
- IP 20 without plate and rocker plate
- IP 40 for assembled product
Material characteristics
PPlate: ABS
Sub-plate: PC
Rocker plate: ABS
Colours: White RAL 9003 – Ivory RAL 1013
Aluminium, Black, Dark Grey
Mechanism casing with support: Fibreglass-reinforced (10 %) PC
Halogen-free
UV resistant
Self-extinguishing: 650°C/30 s
Electrical characteristics
Powered by a CR2032 – 3 V lithium battery (supplied)
Battery life: 8 years for 10 activations a day
ZigBee radio technology frequency: 2.4 GHz to 2.4835 GHz
Wireless mesh network, self-adaptive and secure (AES 128), conforming to standard IEEE 802.15.4 (LR-WPAN)
Power level: < 100 mW
Climatic characteristics
Usage temperature: + 5° C to + 45° C
Storage temperature: 0° C to + 45° C
MAINTENANCE
Clean the surface with a cloth.
Do not use acetone, tar-removing cleaning agents or trichloroethylene.
Resistant to the following products: Hexane, methylated spirit, soapy water, diluted ammonia, bleach diluted to 10%, window-cleaning products, pre-impregnated wipes.
Caution: Always test before using other special cleaning products.
Do not paint the cover plate!
Take care to recycle the battery appropriately.
ACCESSORIES
0 648 71: Repositionable adhesive for wireless control (x 4 supplied)
STANDARDS AND APPROVALS
Compliant with installation and manufacturing standards.
See e-catalogue.
The undersigned, LEGRAND, declares that the radio-electric equipment type (Cat. Nos 7 221 75 – 7 222 75 7 223 75 – 7 224 75 – 7 656 35 – 7 657
35 – 7 658 35 – 7 659 35) complies with directive 2014/53/EU.The full text of the EU declaration of conformity is available on the following website: www.legrand.com/ecatalogue
Customer Support
Technical data sheet: F03709EN/01 Updated: 07/05/2024 Created: 04/03/2024
