Contents
Charging via DC Connector – 1-Slot
The 12V/4A DC power adaptor supports 9V fast charging when the Galaxy Tab Active4 Pro is mounted on the charging cradle. Connect the DC power adapter to the DC jack located on the bottom of the charging cradle. (A)
Hand Strap Direction
Do not hold the hand strap vertically.
The device mounting may not be stable. (C)
Charging the Galaxy Tab Active4 Pro
Slide the Galaxy Tab Active4 Pro downward along the guide and into the charging slot. (B)
Additional Accessories
► Tab Active4 Pro 2-Slot Normal Charging Cradle
► Tab Active4 Pro 4-Slot Normal Charging Cradle
Hand Strap Direction
Do not hold the hand strap vertically.
The device mounting may not be stable. (C)
The device can be stably mounted with the hand strap oriented in any direction, except vertically. (D)
The device status LED will turn orange, signalling that the Galaxy Tab Active4 Pro is now charging. (E)
Charging via DC Connector – 5-Slot
The 12V/10A DC power adaptor supports 9V fast charging when the Galaxy Tab Active4 Pro is mounted on the charging cradle. (F)
Charging the Galaxy Tab Active4 Pro
Slide the Galaxy Tab Active4 Pro downward along the guide and into the charging slot. (G)
The device status LED will turn orange, signalling that the Galaxy Tab Active4 Pro is now charging. (H)
Charging LED Status – 1-Slot
Blinking Green : When the cradle is powered on
Orange : Charging /Fully charged
Blinking Red : Charging Issue
– Overheating
– Charging fault
– Foreign material inside
Charging LED Status – 5-Slot
Blinking Green : When the cradle is powered on
Orange : Charging /Fully charged
Blinking Red : Charging Issue
– Overheating
– Charging fault
– Foreign material inside
