593025001 Snow Blade
Instruction Manual
HUSQVARNA
Art. No: 593 02 50-01
Contents
593025001 Snow Blade
 |
 |
 |
 |
 |
 |
 |
 |
Accessories
IPL, Snow Blade T-30359, 593 02 50-01, 2017-12
Spare parts
Snow Blade
593 02 50-01
| Pos | Part number | Part name | Qty |
| 1 | 576 18 96-01 | Blade | 1 |
| 2 | 593 84 68-01 | Weldment | 1 |
| 3 | 576 18 99-01 | Angle Control Tube | 1 |
| 4 | 531 00 51-36 | Skid | 2 |
| 5 | 531 00 51-38 | Spring | 2 |
| 6 | 531 02 12-50 | Grip | 2 |
| 7 | 531 02 12-57 | Spring | 1 |
| 8 | 593 84 69-01 | Plate, Lock | 1 |
| 9 | 506 59 96-01 | Rubber Strap | 1 |
| 10 | 531 02 11-48 | Nut, Lock | 2 |
| 11 | 531 02 12-52 | Screw | 2 |
| 12 | 531 02 11-93 | Screw | 2 |
| 13 | 531 02 11-92 | Nut, Lock | 1 |
| 14 | 531 02 12-51 | Screw | 1 |
| 15 | 531 02 12-59 | Screw | 1 |
| 16 | 531 02 12-19 | Nut, Lock | 1 |
| 17 | 531 02 11-98 | Nut, Lock | 1 |
| 18 | 531 02 12-99 | Screw | 1 |
| 19 | 531 02 11-97 | Washer | 1 |
| 20 | 535 46 66-28 | Coupling hook | 1 |
T-30359
Puskulevy/Snow blade KOVA P1205, 2017
Husqvarna RC 300
CERTIFICATE Manufacturer: KONEPAJA A. VANNE, KOVA, Veistamontie 16, FIN-24800 HALIKKO, FINLAND, hereby certifies that the machine of type T-30359 conforms to Machine Directive 2006/42/EC concerning essential health and safety requirements in relation to design and manufacture.
Issued at Haiku 2017.
KOVA
KONEPAJA A. VANNE
Declaration of Conformity
In accordance with UK Government Guidance
Product Model / Type:
T-30359
Serial numbers dating from 2023 and onwards.
This declaration is issued under the sole responsibility of the product manufacturer.
The object of the declaration described above is in conformity with the relevant
UK Statutory Instruments and their amendments:
– The supply of Machinery (Safety) Regulations 2008
Issued at Haiku, 31 .1 2.2022
UK importer:
Husqvarna Uk Ltd
Preston Road, Co.
Durham DL5 6UP
Managing Director
Authorized representative for KOVA and responsible for technical documentation
