GURTAM NT19 GPS Tracker Terminal
Contents
Thank you!
Thank you very much for using GPS TRACKER, the user manual will guide how to operate this product, please read it carefully before using it in order to get the correct method of operation. If the appearance, color and accessories of this product are modified, please refer to the actual product. The manufacturer is not liable for faults and omissions which in the user manual.
Product functions & Parameters
Product functions
Location inquiry, geo-fence, vibration alarm, over-speed alarm, historical route playback, drop off alert.
Parameters
| Content | Specs. |
| Network | LTE /GSM |
| Working voltage | DC 3.4V – 4.5V |
| Working current | 4V/65mA |
| Standby current | 4V/8mA |
| Sleep current | 4V/3mA |
| LTE chip | Simcom |
| GPS chip | MT2503 |
| GPS sensitivity | -159dBm |
| GPS accuracy | 5m |
| Time To First Fix | Cold status 35-80s Warm status 35s Hot status 1s |
| Wall charger | 110－220V input
5V output |
| Storage Temp. | -40°C to +85°C |
| Operation Temp. | -20°C to +55°C |
| Humidity | 5%–95% non-condensing |
Product accessories and LED light status
Product accessories
Standard: the device/ charging cable / quick installation user manual / double-sided stickers
Optional: powerful magnetic
Device LED light status
Red LED (Power supply/Charging indicator)
| Light status | Meaning |
| solid | charging |
| off | Finished/not charging/Power off |
Yellow LED(GSM signal)
| Light status | Meaning |
| blink | GSM initialization |
| solid | GPRS normal communication/online |
| off | GSM sleep/power off |
Blue LED (GPS signal)
| Light status | Meaning |
| blink | GPS signal searching |
| solid | GPS location finished |
| off | GPS sleep/power off |
Installation instructions
Preparation before installation
Open the box and check whether the device and the accessories are complete, otherwise please contact your dealer.
SIM card selection, the device works with Micro SIM card, and support full Netcom band.
SIM card installation, there is a small back cover on one side of the terminal, push out the small back cover, pick up the metal cover of the SIM card slot, put the SIM card chip down into the card slot, and cover the metal cover of the card slot.
Note:
- Before installing or removing the SIM card, please switch off the device;
- Should activate the GPRS function of the SIM card;
- Should activate the caller ID function; (activate or not according to the functions you chose.) 4) If your SIM card required you to input the SIM PIN, please refer to your mobile phone user manual to turn off the SIM PIN function. 5) Please ensure that the SIM card is valid.
Installation
We recommend a hidden installation, and we suggest that you ask a professional organization designated by the dealer. Please note the following:
Hidden installation, pay attention to waterproof;
Do not put together with the launch source, such as reversing radar, anti-theft device or other in-vehicle communication equipment;
GSM antenna and GPRS antenna were built-in the device, make sure that the GPS receiving surface (GPS antenna surface without label) is upward (toward the sky), and there is no metal shielding on the top.
Recommended installation location:
- Inside the decorative frame under the front windshield of the car;
- Areas around the front dashboard of the car (non-metallic material surface);
- Under the decorative plate of the rear windshield of the car;
- Inside the car door or the middle column;
- Inside the instrument panel or under the rear seat of the electric bicycle/motorcycle
Proper use of the product: Installation → Switch on → Settings →
Register
Installation: When installing, the GPS antenna surface should face the sky. There should be no electromagnetic wave absorber (such as metal or explosion-proof film).
Switch on: Insert the SIM card with right direction, connect the cable according to the wiring diagram, and then switch on the device.
Register platform account: The registration method varies according to the dealer’s platform, please consult the dealer.
SMS commands and instructions
Send SMS command from user’s SIM card number to the SIM card number which inside the GPS device.
The commands in the following SMS command list are in English input format, and the letters are case-sensitive according to the instruction requirements.
| Common inquiry | SMS command format | Device reply |
| Center number setting | 101#13712345678# | OK |
| Device status query | CXZT | Version, ID, IP, etc… |
| Chinese address inquiry | 123 | Chinese address |
| Latitude and longitude link query | G1234 | Google map link |
| Reset the device | CQ | system reset OK! |
| Restart GPS | CQGPS | GPS reset OK! |
| Restore factory settings | FORMAT | OK |
| APN setting | apn123456 cmnet | SET APN OK |
| APN user name | apnuser123456 user | SET APNUSER OK |
| APN password | apnpasswd123456 password | SET APNPASS OK |
| ignition/motion upload interval | freq,123456,20 | OK |
| Revise Server IP | IP+blank+IP+blank+port Example：IP 106.3.230.234 8185 |
set IP OK |
App operation
Login location service platform
Users can login to the global positioning service platform provided by the dealer, to check the location and status of the vehicle, and perform corresponding operations. Please consult your dealer for the service platform website.
Platform login on computer:
For individual users, please login with the device ID number. The ID number is on the device body and also on the package box. When logging in to the platform, please select IEIM/License number to log in. The default password is: 123456 Enterprise users and fleet users please select the username to log in. User name and password are set by the dealer, please contact your dealer for distribution!
Android APP download, please scan the QR code on the computer, and if Apple mobile phone, please search the APP name in the App store.
Login page operation introduction
Login and add the device into the device list, then you enter the app home page, users can check battery level, location time, motion status, motion direction, speed, address resolution and other information of the device. Click on “Real Time Tracking”, “Historical route” etc…
Real-time tracking operation introduction
Real-time monitoring,
Click the “Real-time Tracking” icon to enter the corresponding page, then can check the vehicle running status, driving route, speed, direction and other information in real time.
Historical route: Playback of the historical route of the device on a certain day or a period of time (suggest no more than 7 days, otherwise the amount of data loaded will be too large)
Click “Select Date” to pop up the calendar: IOS long press on the calendar to enter the multi-day selection mode and that day is the start date, press and hold another day as the end date to view the historical track during the period; Android click and select the range and click on the right
Introduction of commands
- Vibration alarm on: if this command sent successfully, if there are vibration, will receive alarm message.
- Vibration alarm off: Turn off the vibration alarm function.
- Main control number: Receive alarm call, alarm SMS.
- SOS number: Receive SOS call, if the device support.
- Pass-through: Send SMS commands through the APP.
- Smart mode: upload data according to the pre-set time interval, other time does not work, device will not upload position even though vibration.
- Normal mode: if there is vibration or movement, the data is uploaded every 30 seconds (default). Without vibration or movement, the device automatically enters into the power saving mode, the GPS is turned off, and the device is not offline.
- Power saving mode: no vibration or movement, the device automatically enters into the power saving mode, turns off GPS and GPRS, and the device is offline.
- Voice control recording: no
- Simultaneous Location: no
- Upload interval: Set the working status upload interval (unit: second), the default interval is 60 seconds.
- Restart remotely: The device will restart automatically after clicking the command.
- Remote shutdown: no
Trouble shooting
If the device can’t be connected to the background server after first time installation, and the background server shows it is offline, please check the installation correct or not.
If you have any questions for the operation, please refer to the following questions and solutions; if you still can’t solve the problem, please contact your dealer.
| Common Problems | Reasons | Solutions |
| Poor signal | Test at areas where there are high buildings or underground parking lots, where radio waves cannot be sent or received normally. | Use it at a good signal place |
| platform shows device not activated after first installation | Main power supply connected
correct or not |
Do not connect to the main control line of the vehicle |
| SIM inserted not correct | Check the SIM card | |
| LED status | Check if the indicator is blinking or steady | |
| SIM without GPRS activated or SIM card out of charge. | Please contact carrier to activate
GPRS or charge |
|
| Platform map shows incorrect location | GPS no location | Please go to outdoor place where
GPS signal good |
| Vehicle did not move after installation | Please drive the vehicle on the road | |
| ACC connected or not | Connect the device and turn on ACC | |
| Platform shows the main power disconnect | Poor power supply connection | Check whether the power supply line of the device connected correct or not |
| Platform shows device offline | SIM card out of charge of GPRS was canceled | Please check your SIM card |
| Weak signal area | Please try again at good signal area |
FCC Warning
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.
