General Measure GMC-P7 Touch Screen Weighing Controller Instruction Manual

General Measure GMC-P7 Touch Screen Weighing Controller Instruction Manual

DESCRIPTION

Application Software

Multiple Software Selection:

• Simplex packing;
• Duplex packing;
• Reduce weight method packing;
• Bulk Scale (Continuous weighing);
• Batching scale.

User-friendly Design

• 7-inch touch screen, interactive design, and easy operation;
• Record the weight of every pack, million data storage and export.

Multi-Mode

Multi-Mode: With Hopper, No Hopper, Big Bag Scale, Valve Scale, PLC;

Adaptive Function

Automatic drop correction function, feeding speed adaptive function;

Patting Mode
Starting Patting mode when filling material to shape bags by setting relevant parameters;

Robust & Durable

Strong anti-interference

• Metal case with SS304 and aluminum provides better EMC protection and screen protection;
• 500mA over-current protection for IO port;


Sealing & Dust-proof performance

• 3mm front panel with rubber seal strip makes it fit control box well, which improves the sealing and dust-proof performance;


External keyboard

Support mouse and keyboard control by USB connection;

MCU

MCU with quad-core (Linux) for fast images and data processing ability

Harsh desk/wall mount version

Provide harsh desk/wall mount version for installation;

Multiple Communication Methods

• RS232+RS485 for connecting PC, PLC, Printer, Label Printer, Remote Display, Code Printer, or other external devices, for reading and setup remotely;
• 12 Input/16 Output for starting, stopping, unloading, clamping/loosening bags, etc.;
• Modbus TCP for connecting PC, PLC, Printer, etc., for reading remotely;
• USB for importing and exporting recipes, I/O function communication parameters and other working parameters, upgrading system software, customizing boot screen, etc.


Standard Specification
General Specifications	Model	GMC-P7 (CoPro Series)
	Power Supply	DC 24V plus or minus 5%
	Working temperature	-10℃~40℃
	Maximum humidity	90% R.H without dew
	Testing standards	Class Ⅲ 6000 e, 1 μ V/d
	Power consumption	About 15 w
A/D Conversion	A/D performance	24 bit Delta-Sigma
	A/D conversion speed	120/240/480 times/per second
	Non-linearity	0.01%F.S
	Gain drift	10PPM/℃
	Input sensitivity	0.02μV/d
	Display Accuracy	1/100,000
	Input range	0.02~15mV
	Sensor power supply	DC5V 125mA(Max)
	Input impedance	10MΩ
	Zero steady range	Maximum 0.002 ~ 15mV(Load Cell 3mV/V)
Application Software	Simplex packing; Reduce weight method packing; Batching scale.	Duplex packing; Bulk Scale (Continuous weighing);
Function extension	Equipped with GMA-X1 automatic traction module, reduce workforce cost

Dimension

Application

• Simplex Packing

• Duplex Packing

• Reduce Weight Method Packing

• Bulk Scale (Continuous weighing)

• Batching Scale
