FOS technologies L005679 NAXOS 12A DSP Professional ABS Plastic Active Speaker User Guide

L005679 NAXOS 12A DSP Professional ABS Plastic Active Speaker
User Guide

Professional ABS plastic active speaker 12 inch with DSP, 1,35?? HF driver, RMS 300W(LF)+50W(HF) 350w RMS, German Engineering D class amplifier, 121 dB Spl, XLR, TRS line, Mic, bluetooth .

Contents

TECHNICAL DETAILS

Technical Specifications
2 way active full range speaker.
Inputs: Bal XLR/TRS, 6.35, AUX, Bluetooth.
Outputs: Balanced XLR / TWS.
Power output: 250W (LF) + 50W (HF) RMS.
Bluetooth version: 5.0
Power Input: 100/240 Volt AC, 50/60 Hz switchable.
Features: LF: German Engineering class D, HF: Class-AB.
DSP signal processing.
DSP parameters: Standard, Vocal boost, Live, Stage monitor.
EQ: Bass / Treble.
Frequency Range: 55 – 20 kHz.
Max output SPL: 125dB (at max AMP output).
Impedance: LF 4Ù / HF 8Ù.
1.35″ compression driver.
12″ woofer.
HPP molded cabinet.
35mm stand pole.
Packing Details
Dimensions: 46 x 43 x 66 cm.
Weight: 18 Kgs.
