DELL Latitude 9430-02 Portable Laptop

DELL-Latitude-9430-02-Portable-Laptop-product-image

Product Information

The Latitude 9430-02 2-in-1 is a versatile laptop and tablet hybrid designed and manufactured by Dell. It comes with various features and specifications to enhance your computing experience. The product is certified by MCMC and complies with RoHS and CNS15663 standards. For more information about the product, you can visit Dell’s environmental information materials page at https://www.dell.com/learn/tw/zh/twcorp1/envt-info-materials.

Product Usage Instructions

Safety Precautions:

  • Read the safety information that shipped with your computer.
  • For additional safety best practices information, see the Regulatory Compliance Homepage at Dell.com/regulatory_compliance.
  • Do not remove the computer cover unless you need to install internal accessories.
  • Retain the filler brackets or cards that ship with your computer to maintain FCC certification and protect your computer from dust and dirt.

System Information:

  • For Windows users: In Windows Search, type “System” and click on “System” in the search results.
  • For Ubuntu users: On the desktop, click on “About This Computer”.

Support and Manuals:

  • For instructions on removing and replacing parts, refer to the
    Owner’s or Service Manual at Dell.com/support.

Note: It is important to adhere to the provided instructions to ensure proper usage and maintenance of your Dell Latitude 9430-02 2-in-1.

Information Guide

Regulatory Model/Type
P142G/ P142G002

Información para NOM, o Norma Oficial Mexicana

MCMC certification mark
Windows
In Windows Search, type System. In the search results, click System.
Ubuntu
On the desktop, click →About This Computer.
Di impor oleh:
PT Dell Indonesia
Menara BCA Lantai 48 Unit 4804
Jalan M.H Thamrin No. 1 Jakarta Pusat,
10310 Indonesia
Connection and use of this communications equipment is permitted by the Nigerian Communications Commission.
https://www.dell.com/learn/tw/zh/twcorp1/envt-info-materials

Read the safety information that shipped with your computer. For additional safety best practices information, see the Regulatory Compliance Homepage at Dell.com/regulatory_compliance.
Do not remove the computer cover unless you need to install internal accessories for your computer. For instructions on removing and replacing parts, see the Owner’s or Service Manual at Dell.com/support.
Retain the filler brackets or cards that ship with your computer. Installing filler brackets or filler cards over empty card-slot openings is necessary to maintain FCC certification of the computer. The filler brackets and filler cards keep dust and dirt out of your computer and maintain the airflow that cools your computer.

Power Adapter

  • Input voltage
    100-240 V AC
  • Input current (maximum)
    1.3 A
  • Input frequency
    50-60 Hz
  • Output current
    2.31 A
  • Output voltage
    19.5 V DC
  • Maximum operating temperature
    °C ( °F)

Connect the power adapter or the power cable to your computer and to the display, if required.

DELL-Latitude-9430-02-Portable-Laptop-1

Power on the computer (and the display, if connected).

DELL-Latitude-9430-02-Portable-Laptop-2

Depending on your computer configuration, some ports or connectors may not be available.

Icons

  • Power adapter
    DELL-Latitude-9430-02-Portable-Laptop-3
  • USB 2.0
    DELL-Latitude-9430-02-Portable-Laptop-4
  • USB 3.0/USB 3.1 Gen 1
    DELL-Latitude-9430-02-Portable-Laptop-5
  • USB 3.0/USB 3.1 with PowerShare
    DELL-Latitude-9430-02-Portable-Laptop-6
  • USB 3.0/USB 3.1 with PowerShare
    DELL-Latitude-9430-02-Portable-Laptop-7
  • eSATA
    DELL-Latitude-9430-02-Portable-Laptop-8
  • Thunderbolt
    DELL-Latitude-9430-02-Portable-Laptop-9
  • Thunderbolt 3 port with Power delivery (USB-C)
    DELL-Latitude-9430-02-Portable-Laptop-10
  • Network
    DELL-Latitude-9430-02-Portable-Laptop-11
  • VGA
    DELL-Latitude-9430-02-Portable-Laptop-12
  • DVI
    DELL-Latitude-9430-02-Portable-Laptop-13
  • HDMI
    DELL-Latitude-9430-02-Portable-Laptop-14
  • DisplayPort
    DELL-Latitude-9430-02-Portable-Laptop-15
  • Mini DisplayPort
    DELL-Latitude-9430-02-Portable-Laptop-16
  • TV-in
    DELL-Latitude-9430-02-Portable-Laptop-17
  • External Graphics Port
    DELL-Latitude-9430-02-Portable-Laptop-18
  • Infrared (IR) emitter
    DELL-Latitude-9430-02-Portable-Laptop-19
  • Headphone/Audio-out
    DELL-Latitude-9430-02-Portable-Laptop-20
  • Headset
  • Microphone
  • Line-in
  • Line-out/Speakers: front left-right
  • Speakers: rear left-right
  • Speakers: side left-right
  • Speakers: Audio center/subwoofer
  • S/PDIF
    DELL-Latitude-9430-02-Portable-Laptop-28
  • Screen-rotation lock
    DELL-Latitude-9430-02-Portable-Laptop-29
  • SIM-card slot
    DELL-Latitude-9430-02-Portable-Laptop-30
  • ExpressCard slot
    DELL-Latitude-9430-02-Portable-Laptop-31
  • Media-card reader
    DELL-Latitude-9430-02-Portable-Laptop-32
  • Security-cable slot
    DELL-Latitude-9430-02-Portable-Laptop-33
  • Power/Battery-status light
    DELL-Latitude-9430-02-Portable-Laptop-34
  • Battery-status light
    DELL-Latitude-9430-02-Portable-Laptop-35
  • Hard-drive activity light
    DELL-Latitude-9430-02-Portable-Laptop-36
  • Wi-Fi light
    DELL-Latitude-9430-02-Portable-Laptop-37
  • Bluetooth light
    DELL-Latitude-9430-02-Portable-Laptop-38
