decon MEM6247 GTM Hammer Vario Instruction Manual

1. Remove wheels, sleeves and nuts.

2. Check the correct placement for the eMove, and that it is axle Ø12,0 x 51 with Part Number: XOE-2530E-BO and Spacer with Part Number: XOE-25383-00.

3. Assembly the plates according to pictures.

Parts for right side mounting:

Note! If you only order the mounting set, the axle, axle spacer and the Circlip are not included, for replacement see the service manual.

4. Assemble the under placed battery bag.
