CRYSTORAMA DUM-9808-GE Dumont Outdoor 3 Light Post Mount
Contents
WARNING
All electrical components must be installed by a licensed electrician in accordance with the National Electric Code and the appropriate local electrical codes.
You will need 3-Medium Bulb 40 Watts Recommended 60 Watts Max Bulb not included
USE LED BULBS FOR EXTENDED USE This fixture is WET rated
Dimensions
How to Install
- Place the fixture over the post and mark 3 points on the post at the center of holes on the post fitter.
- Drill the holes at the marked points
- Connect the fixture wires, then place the fixture over the post by aligning the holes on the fitter with the holes drilled on the post. Secure by tightening with side screws.
How To Change Glass
- Remove the screws on the top of the cage and remove the cage
- Remove the L-shaped metal strap by unscrewing the screws.
- Smooth out the silicone glue along the glass channel, prior to placing in the new glass panel.
- Put the new glass panel on and secure it with the L-shaped metal strap and screws.
Sketch Map
WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer and/or birth defects or reproductive harm. For more information go to www.P65Warnings.ca.gov
Part Number
A. Mounting Hardware
(3)Screw
(3)Wire Nut
B. (1)Base;Ø3.4″x3.5″H
C. (3)Socket
D. (1)Bottom cage
E. (4)Glass;XMO9803GEGLA12IN
F. (1)Top cage
E-Glass Size
