AMAX LED-RSM63DL-WT Pancake Disc Series With Built-In Radar Sensor
Contents
Specifications
Description
This 7 inch radar sensor LED ceiling mount light is a perfect solution for areas where you need light to automatically turn on when motion is detected. This light features a 17 second duration of light when motion is detected, and with range up to 4.5-5.5 yards. Providing 780 lumens, 3000K warm white. The ideal luminaire to apply in a: closet, bathroom, hallway, stairway, kitchen, workplace, garage, basement, storage or utility room. Wet location rated.
Features
Diffused polycarbonate lens controls direct glare from the LEDs Aluminum construction with a polycarbonate trim ring Simple snap in installation for J-Box Can be installed in a 3″ or 4″ J-Box Turns off after 17 second delay if no motion is detected Turns on when motion is detected, in the dark or daytime Sensing distance: 4.5-5.5 yards Radar occupancy sensor
Performance
| Input Power | 13W |
| Input Voltage | 120V |
| Input Frequency | 60Hz |
| Power Factor | ≥0.90 |
| Lumen | 780 |
| CCT | 3000K |
| CRI | 90+ |
| Back Convex Dimension | 2 1/8″x5/8″ |
| Life | 50,000 hrs |
| Warranty | 5 years Limited |
| Certification | SGS Certified, Wet Location |
Catalog Number
|
Item |
Finish | Color Temp. | Watt | Dimension |
|
LED RSM63DL/WT |
White | 3000K | 13W |
5.5″x5.5″x1/2″ |
Customers Support
10268 Santa Fe Springs Road, Santa Fe Springs, CA 90670
Tel: 562-945-5221 Fax: 562-464-1664
www.amaxlighting.com
