AM101/850W
AM101/1120W
(WOOD)
AM101 Self Supporting Frame for Wall Hung Toilets
| (H1) | H2 | (H3) | H4 | |
| AM101/850W | 866 | 480 | 780 | 390 |
| AM101/1120W | 1120 | 680 | 980 | 593 |
The dimensions indicated in parentheses are for reference only. If the abbreviation ,CZ“ is indicated for any dimension in the picture, it means that this dimension corresponds to the legal regulations and standards of the Czech Republic. If the installation is carried out in another country, the person carrying out the installation is obliged to adjust such a dimension in accordance with the legal regulations and standards of the other country. The person carrying out the installation is responsible for the correct installation and height adjustment of the pre-wall installaton system. The height adjustment of the pre-wall installaton system is determined by the type of toilet bowl used, the toilet seat and the content of legal regulations and standards of the country in which the installation is performed.
16
Producer: Alcadrain s. r. o., Komunardd 1626/35,
170 00 Praha 7 — Holesovice, CZ
Declaration of performance Nr. 06/2016
Wall-mounted installation systems: AM100, AM101, AM102, AM112, AM115, AM116, A108F, AM113
| Basic characteristics | Properties | Harmonized technical specification |
| Water tightness | Compliant | EN14055 |
| Reliability of the drain valve | Category 1 | EN14055 |
| Noise level | Group 1 | EN14055 |
| Flush volume | Compliant | EN14055 |
| Durability | Compliant | EN14055 |
Personal hygiene — PH
EN 14055 -CL1-6-NLI-VRI
Alcadrain s. r.o.
Bratislavskd 2846
690 02 Breclav
Ceska republika
Tel.: +420 519 821 117 – prodej CR
Tel.: +420 519 821 041 – export
Fax: +420 519 821 083
e-mail: [email protected]
www.alcadrain.cz
R0/04/22/NA0154
